PCBA AOI Equipment

Automated Optical Inspection Equipment is a cutting-edge technology used in various industries to enhance the quality control process of manufactured products. This advanced system employs high-resolution cameras and intelligent algorithms to scan and analyze components, circuit boards, or assemblies for defects, ensuring they meet strict quality standards. AOI Equipment is capable of detecting a wide range of anomalies, including soldering defects, misalignments, missing components, and solder bridges. By automating the inspection process, AOI Equipment significantly reduces the likelihood of human error, increases inspection speed, and improves overall production efficiency. This technology has become a cornerstone in modern manufacturing, particularly in electronics, semiconductor, and automotive industries, where precision and reliability are paramount. With its ability to swiftly identify and rectify potential issues, AOI Equipment plays a crucial role in guaranteeing the integrity and performance of products before they reach the end-users.

SMT AI 3D AOI Equipment

3D AOI (Automatic Optical Inspection) Equipment can accurately inspect and measure the height dimensions of devices on PCBs, and provide clear side view images of ICs and various devices. When detected automatically, the AOI Equipment automatically scans the PCB through the camera, collects images, and compares the tested solder joints with the qualified parameters in the database. After image processing, the defects on the PCB are inspected and displayed/marked by display or automatic marking. This seamless integration of AOI Equipment into the inspection process enhances accuracy and efficiency, ensuring that manufactured products meet rigorous quality standards.

SMT AI 3D SPI AOI Equipment

The automatic 3D solder paste inspection system is a desktop fully automatic 3D solder paste inspection equipment designed for the SMT process, fully programmable and automatic. With the integration of AOI Equipment, it only takes a few minutes to check the whole circuit board, and the SPC result can be given. One such automatic 3D solder paste inspection system equipment can support multiple SMT production lines. This seamless combination of advanced technologies significantly enhances the efficiency and accuracy of the solder paste inspection process, ensuring high-quality PCB assemblies in the SMT production environment.

SMT AI 2D AOI Equipment

Особенности продукта

Introducing our advanced AOI Equipment, featuring an integrated casting molding frame for enhanced stability. This state-of-the-art system boasts a multi-angle light source coupled with a high-resolution camera and telecentric lens, significantly augmenting the detection capabilities. Moreover, it incorporates the latest self-developed AAM absolute precision measuring system, enabling pinpoint accuracy in detecting even the smallest 0201 component solder joints.

In addition, our AOI Equipment seamlessly connects and integrates with MES systems, tailored to the specific requirements of your factory. This integration ensures streamlined and efficient operations. To further bolster quality control, our equipment is equipped with powerful SPC software, offering comprehensive and precise statistical analysis.

To guarantee both speed and precision in motion, our AOI Equipment is equipped with a high-precision motion system. This feature assures rapid yet accurate movements, ultimately contributing to a more efficient and reliable inspection process.

DIP AI AOI Equipment (Pre wave soldering)

Incorporated seamlessly with advanced AOI equipment, the DIP PCBA AI Machine is meticulously engineered for thorough plug-in inspections conducted prior to the soldering process. This strategic integration serves as an essential quality control measure, ensuring that a wide array of potential defects, including errors, leakages, reversals, overdoses, and skewing, are swiftly pinpointed and rectified.

What truly sets our system apart is its unparalleled efficiency in template generation. Gone are the days of cumbersome manual parameter adjustments. With a single click, the machine initiates an intelligent search across an extensive array of equipment, spanning more than 80 distinct types. This streamlined process not only expedites the inspection procedure but also guarantees a comprehensive and meticulous examination of every component.

This harmonious integration of AOI equipment with our DIP PCBA AI Machine fosters a seamless and highly productive workflow. This ensures that any potential issues are identified and resolved promptly, minimizing disruptions and optimizing the overall manufacturing process.

DIP AI AOI Equipment(Post Wave Soldering)

Post Wave Soldering DIP PCBA AI-AOI Equipment bottom type Alpha Z510-D.

Independent design, and strive for the extreme

  • The self-developed movement module operates at a high speed Realize higher UPH to improve plant efficiency.
  • Handle the whole industry’s largest PCB board.
  • The minimum size of the whole industry helps factories to save plant space. (compared to the same specification series of products)


Особенности продукта

  • Простой интерфейс работы, значительно сокращающий новое время обучения
  • Уменьшите нагрузку на персонал при визуальном осмотре и улучшите производительность обработки
  • Вывод отчетов о продуктах для анализа
  • Простой интерфейс работы, повысить эффективность использования
  • Высококачественная технология обнаружения выборки, точное обнаружение различных дефектов
  • Изучите интеллектуальный дизайн программного обеспечения, простую и быструю настройку номера материала
  • Настольная передача с большой нагрузкой, размер гибкой платы / HDI-платы значительно увеличен
  • Двойная подача одинарного/двойного режима обнаружения, повышение скорости производства обнаружения
  • Стандартизация тестирования, значительно уменьшить человеческий фактор
  • Высокое разрешение цветной ПЗС-матрицы
  • Сверхвысокая яркость светодиода обеспечивает стабильный разнонаправленный источник света
  • Возможность обнаружения и анализа ИИ

PCBA AOI Equipment: Enhancing Precision in Electronics Manufacturing

Key Advantages Описание
1. Automated Inspection Achieve unparalleled efficiency with automated optical inspection, reducing the need for manual labor and ensuring consistency in quality control.
2. High Accuracy Imaging Benefit from advanced imaging technology for high-resolution inspection, detecting minute defects in components with precision and reliability.
3. Rapid Inspection Speed Boost production efficiency with rapid inspection capabilities, minimizing cycle times and optimizing overall throughput in PCB assembly.
4. Defect Identification Our AOI Equipment employs intelligent algorithms to swiftly identify and classify defects, facilitating prompt corrective measures for improved production yields.
5. Versatility Adaptable to various PCBA types and configurations, our equipment caters to the diverse needs of electronics manufacturing, ensuring flexibility in application.
6. User-Friendly Interface Intuitive interfaces and easy-to-use controls enhance user experience, enabling quick integration into existing manufacturing workflows with minimal training.
7. Real-time Feedback Receive real-time feedback on production quality, allowing for immediate adjustments and continuous improvement in the manufacturing process.
8. Quality Assurance Elevate your quality assurance protocols with our PCBA AOI Equipment, ensuring adherence to the highest industry standards and delivering reliable, defect-free products.

Invest in our state-of-the-art PCBA AOI Equipment, where precision, speed, and adaptability converge to redefine excellence in electronics manufacturing. Trust in our commitment to advancing your production capabilities with cutting-edge technology and unwavering quality assurance.
